The TC130 series is a high-torque 130 mm brushless DC motor with rated power from 1.5 to 6.0 kW. Available voltage options include 24, 48, 72, and 310 V DC or 220 V AC. Rated speeds range from 1,500 to 3,000 rpm, with rated torque up to 19.1 N.m and peak torque up to 40 N.m.
Model | Voltage | Rated Power | Rated Speed | Rated Current | Rated Torque | Peak Torque | No-load Current | Weight | Motor Length L |
TC130BLD1500-24A-15S | 24 | 1500 | 1500 | 78 | 9.5 | 20 | ≤10 | 10 | 193 |
TC130BLD2000-48A-20S | 48 | 2000 | 2000 | 52 | 9.5 | 20 | ≤7.5 | 10 | 193 |
TC130BLD3000-24A-30S | 24 | 3000 | 3000 | 152 | 9.5 | 20 | ≤15 | 10 | 193 |
TC130BLD3000-48A-30S | 48 | 3000 | 3000 | 78 | 9.5 | 20 | ≤10 | 10 | 193 |
TC130BLD3000-310A-15S | 310/AC220 | 3000 | 1500 | 12 | 19.1 | 40 | ≤2 | 16 | 290 |
TC130BLD3000-48A-20S | 48 | 3000 | 2000 | 76 | 14.3 | 30 | ≤10 | 13 | 238 |
TC130BLD3000-72A-30S | 72 | 3000 | 3000 | 51 | 9.5 | 20 | ≤7.5 | 10 | 193 |
TC130BLD3000-310A-30S | 310/AC220 | 3000 | 3000 | 12 | 9.5 | 20 | ≤2 | 10 | 193 |
TC130BLD5000-48A-30S | 48 | 5000 | 3000 | 124 | 15.9 | 35 | ≤14 | 13.5 | 238 |
TC130BLD5000-72A-30S | 72 | 5000 | 3000 | 83 | 15.9 | 35 | ≤10 | 13.5 | 238 |
TC130BLD5000-310A-30S | 310/AC220 | 5000 | 3000 | 19 | 15.9 | 35 | ≤3 | 13.5 | 238 |
TC130BLD6000-48A-30S | 48 | 6000 | 3000 | 149 | 19.1 | 40 | ≤15 | 16 | 290 |
TC130BLD6000-72A-30S | 72 | 6000 | 3000 | 99 | 19.1 | 40 | ≤12 | 16 | 290 |
TC130BLK1800-48A-30S | 48 | 1800 | 3000 | 47 | 5.7 | 12 | ≤7.5 | 7.5 | 125 |
TC130BLK1800-310A-30S | 310/AC220 | 1800 | 3000 | 7 | 5.7 | 12 | ≤1.2 | 7.5 | 125 |
TC130BLK2500-48A-30S | 48 | 2500 | 3000 | 65 | 8.0 | 16 | ≤9 | 9 | 155 |
TC130BLK2500-72A-30S | 72 | 2500 | 3000 | 43 | 8.0 | 16 | ≤6.0 | 9 | 155 |
TC130BLK3000-48A-30S | 48 | 3000 | 3000 | 78 | 9.5 | 20 | ≤10 | 11 | 195 |
TC130BLK3000-72A-30S | 72 | 3000 | 3000 | 52 | 9.5 | 20 | ≤7.5 | 11 | 195 |
TC130BLK3000-310A-30S | 310/AC220 | 3000 | 3000 | 12 | 9.5 | 20 | ≤2 | 11 | 195 |
TC130BLK4700-48A-30S | 48 | 4700 | 3000 | 122 | 15.0 | 30 | ≤14 | 13 | 195 |
TC130BLK4700-72A-30S | 72 | 4700 | 3000 | 82 | 15.0 | 30 | ≤10 | 13 | 195 |
TC130BLK4700-310A-30S | 310/AC220 | 4700 | 3000 | 19 | 15.0 | 30 | ≤3 | 13 | 195 |
Customization note: Voltage, power, speed, ambient temperature (default: -10°C to +40°C), and IP class (default: IP54) can be customized.
