The TCJ2035 is a compact 20 mm brushless DC motor available in 12 V and 24 V versions. It delivers rated power from 11 to 17 W, rated speeds from 6,000 to 7,800 rpm, and rated torque from 125 to 132 gf.cm. PWM speed control, CW/CCW rotation, FG signal output, and motor protection are supported.
Model | Rated Voltage | No-load | No-load | Rated | Rated | Rated | Rated | Stall | Stall | Parameters | Parameters | Parameters |
Model | Rated Voltage | Speed | Current | Torque | Speed | Current | Power | Torque | Current | Torque Constant | Speed Constant | Speed/Torque Constant |
Model | V | RPM | A | gf.cm | RPM | A | W | gf.cm | A | gf.cm/A | RPM/V | RPM/gf.cm |
TCJ2035-1270 | 12 | 7000 | 0.14 | 125.0 | 6000 | 0.9 | 11 | 900 | 6.00 | 160 | 600 | 7.4 |
TCJ2035-2495 | 24 | 9500 | 0.15 | 132.0 | 7800 | 0.7 | 17 | 765 | 3.50 | 234 | 414 | 12.4 |
