TCK1635-PG16 16 mm Slotless Brushless DC Planetary Gearmotor, 12/24 V

Specifications

Model: TCK1635-12150-PG16-XX / TCK1635-24150-PG16-XX
Rated Voltage: 12 V / 24 V
Rated Power: 13 W / 15 W
Gearbox Reduction Ratio: 4-3,027
Share as

Introduction

The TCK1635-PG16 combines a compact 16 mm brushless DC motor with a precision planetary gearbox for high-torque, low-speed operation. Available for 12 V or 24 V operation, it delivers rated power from 13 to 15 W. Gear ratios from 4:1 to 3,027:1 provide rated output speeds from 4 to 3,225 rpm and torque up to 2.4 kgf.cm.

Model Dimension Drawings

Advantages

Higher-output geared design: Combines a higher-output slotless brushless motor with a compact 16 mm planetary gearbox.
Extensive ratio selection: Reduction ratios from 4:1 to 3,027:1 support diverse speed requirements.
Multiple torque options: Provides rated output torque of up to 2.4 kgf.cm, depending on the selected ratio.
Efficient power transmission: Gearbox efficiency reaches up to 80%, depending on the number of gear stages.
Flexible voltage options: Available in both 12 V and 24 V versions.
Request A Quote

Motor Performance Parameters

Model

Rated Voltage (V)

No-load Speed (RPM)

No-load Current (A)

Rated Torque (gf.cm)

Rated Speed (RPM)

Rated Current (A)

Rated Power (W)

Stall Torque (gf.cm)

Stall Current (A)

TCK1635-12150

12

14800

0.16

72

12900

1.11

13

557

7.50

TCK1635-24150

24

15000

0.11

85

12800

0.68

15

583

4.00

Geared Motor Performance Parameters

Reduction Ratio

12V No-load Speed (RPM)

12V No-load Current (A)

12V Rated Torque (kgf.cm)

12V Rated Speed (RPM)

12V Rated Current (A)

12V Rated Power (W)

12V Efficiency (%)

12V Length L (mm)

24V No-load Speed (RPM)

24V No-load Current (A)

24V Rated Torque (kgf.cm)

24V Rated Speed (RPM)

24V Rated Current (A)

24V Rated Power (W)

24V Efficiency (%)

24V Length L (mm)

4

3700

0.16

0.23

3225

1.11

13

80

51.35

3750

0.11

0.27

3200

0.70

15

80

51.35

14

1057

0.16

0.71

921

1.11

13

70

55

1071

0.11

0.83

914

0.70

15

70

55

16

925

0.16

0.81

806

1.11

13

70

55

938

0.11

0.95

800

0.70

15

70

55

19

779

0.16

0.96

679

1.11

13

70

55

789

0.11

1.13

674

0.70

15

70

55

29

510

0.16

1.46

445

1.11

13

70

55

517

0.11

1.73

441

0.70

15

70

55

53

279

0.16

2.29

243

1.11

13

60

58.35

283

0.11

2.40

242

0.70

15

60

58.35

62

239

0.16

2.40

208

1.11

13

60

58.35

242

0.11

2.40

206

0.70

15

60

58.35

72

206

0.16

2.40

179

1.11

13

60

58.35

208

0.11

2.40

178

0.70

15

60

58.35

84

176

0.16

2.40

154

1.11

13

60

58.35

179

0.11

2.40

152

0.70

15

60

58.35

104

142

0.16

2.40

124

1.11

13

60

58.35

144

0.11

2.40

123

0.70

15

60

58.35

128

116

0.16

2.40

101

1.11

13

60

58.35

117

0.11

2.40

100

0.70

15

60

58.35

157

94

0.16

2.40

82

1.11

13

60

58.35

96

0.11

2.40

82

0.70

15

60

58.35

231

64

0.16

2.40

56

1.11

13

50

62.4

65

0.11

2.40

55

0.70

15

50

62.4

284

52

0.16

2.40

45

1.11

13

50

62.4

53

0.11

2.40

45

0.70

15

50

62.4

370

40

0.16

2.40

35

1.11

13

50

62.4

41

0.11

2.40

35

0.70

15

50

62.4

390

38

0.16

2.40

33

1.11

13

50

62.4

38

0.11

2.40

33

0.70

15

50

62.4

455

33

0.16

2.40

28

1.11

13

50

62.4

33

0.11

2.40

28

0.70

15

50

62.4

561

26

0.16

2.40

23

1.11

13

50

62.4

27

0.11

2.40

23

0.70

15

50

62.4

690

21

0.16

2.40

19

1.11

13

50

62.4

22

0.11

2.40

19

0.70

15

50

62.4

850

17

0.16

2.40

15

1.11

13

50

62.4

18

0.11

2.40

15

0.70

15

50

62.4

1014

15

0.16

2.40

13

1.11

13

40

66.05

15

0.11

2.40

13

0.70

15

40

66.05

1621

9

0.16

2.40

8

1.11

13

40

66.05

9

0.11

2.40

8

0.70

15

40

66.05

1996

7

0.16

2.40

6

1.11

13

40

66.05

8

0.11

2.40

6

0.70

15

40

66.05

3027

5

0.16

2.40

4

1.11

13

40

66.05

5

0.11

2.40

4

0.70

15

40

66.05
