The TC60-GN-LC combines the supplied 57/60 mm brushless DC motor with the L-type right-angle reduction gearbox. The supplied catalog specifies 25 W, a rated motor speed of 2500 rpm, rated motor torque of 0.096 N·m, and peak motor torque of 0.144 N·m. Available voltage and reduction-ratio options are listed in the tables below.
Model | Voltage (V) | Rated Power (W) | No-load Speed (rpm) | Rated Speed (rpm) | Rated Current (A) | Rated Torque (N.m) | Peak Torque (N.m) |
TC60-24-15-25S | 24 (36/48 optional) | 25 | — | 2500 | 1.7 | 0.096 | 0.144 |
Gearhead Type | Gearhead Model | Available Reduction Ratios |
L-type right-angle reduction gearbox | TC60-□GN-15/25-25S-LC | 5, 10, 15, 20, 30, 50, 100, 200 |
Catalog note: actual output speed may be approximately 2%-20% lower than the calculated value, depending on load.
